Hex AND Calculator
Bitwise AND two hex values and see the result bit by bit — the operation low-level code uses to mask out (clear) unwanted bits.
Binary, aligned by bit
Built by
Swapnil SanghviFull-Stack Web Developer & WordPress Developer
Swapnil Sanghvi is a full-stack web and WordPress developer, UI designer, and full-time freelancer who builds and maintains Hex Calculator.
Further reading: Bitwise operation — Wikipedia
How to AND Two Hex Values
Line the two values up bit by bit. For each position, the result bit is 1 only if both inputs have a 1 there — if either input has a 0, the result bit is 0. It's the strictest of the bitwise operations: every bit has to "agree" on 1 to survive.
Hex AND Example, Step by Step
1234 AND 00FF = 0034
0x1234 & 0x00FF = 0x0034
0001 0010 0011 0100 & 0000 0000 1111 1111 --------------------- 0000 0000 0011 0100
| Step | Description | Result |
|---|---|---|
| Align bits | 1234 = 0001001000110100, 00FF = 0000000011111111 | 16 bits each |
| AND each bit pair | top byte ANDed with all zeros clears it; low byte ANDed with all ones keeps it | top byte cleared, low byte kept |
| Result | only the low byte of 0x1234 survives | 0x0034 |
This is the standard 'mask off the low byte' pattern — ANDing with 0x00FF always clears everything except the lowest 8 bits, regardless of what the original value was.
Where Hex AND Actually Comes Up
Isolating a Byte From a Larger Value
ANDing a 16- or 32-bit value with 0xFF keeps only the lowest byte and clears the rest — a routine step when unpacking a multi-byte value one byte at a time.
value & 0xFF -> low byte only
Checking If a Specific Flag Bit Is Set
ANDing a status register against a single-bit mask and checking whether the result is nonzero is the standard way to test one flag without disturbing the others.
status & 0x04 tests bit 2
Rounding Down to a Power-of-Two Boundary
ANDing an address against the inverse of an alignment mask clears the low bits, rounding the address down to the nearest aligned boundary — common in memory allocators.
addr & ~0xF aligns to 16 bytes
Why Use This Calculator Instead of Doing It by Hand
- Shows aligned binary for both operands and the result, not just the final hex
- Supports 8/16/32/64-bit widths so leading zero bits are handled correctly
- Runs entirely in your browser — nothing you type gets sent anywhere
- Includes OR, XOR, and NOT in the same calculator if you need to switch operations
Limitations
- Combines two values at a time — chain results manually if you need to AND three or more values together.
- The bit-width setting only controls how the binary breakdown is padded and displayed — it doesn't change which bits the AND itself compares.
Frequently Asked Questions
How does bitwise AND work?
AND compares two values bit by bit — a result bit is 1 only when both inputs have a 1 in that position, otherwise it's 0.
What is AND used for in practice?
Masking — ANDing a value against a mask clears every bit outside the mask, which is how code isolates a specific field (like a single byte) out of a larger value.
Why is 0xFF a common AND mask?
0xFF is eight 1 bits, so ANDing any value with it keeps only the low 8 bits (one byte) and clears everything above that — a very common way to isolate the low byte of a larger number.
Does bit width change an AND result?
Not the AND itself — AND only combines bits that exist in both operands — but the bit width controls how many leading zero bits each operand is padded to before comparing, which matters if you're checking a specific bit position.
What's the difference between AND and OR here?
AND clears bits (needs both inputs to have a 1 to keep it); OR sets bits (needs only one input to have a 1). Use AND to mask down, OR to combine flags up.
