Hex Bitwise Calculator
Run AND, OR, XOR, and NOT on hex values with a bit-width selector and aligned binary output showing exactly how each bit combines.
Binary, aligned by bit
Built by
Swapnil SanghviFull-Stack Web Developer & WordPress Developer
Swapnil Sanghvi is a full-stack web and WordPress developer, UI designer, and full-time freelancer who builds and maintains Hex Calculator.
Further reading: Bitwise operation — Wikipedia
How Bitwise Operations Work
Each bitwise operation compares two values one bit at a time (or, for NOT, inverts one value one bit at a time). AND keeps a result bit only when both inputs have that bit set; OR sets a result bit when either input does; XOR sets a result bit only when the inputs disagree; NOT simply flips every bit.
Hex AND Example, Step by Step
F0 AND 0F = 00
0xF0 & 0x0F = 0x00
1111 0000 & 0000 1111 ----------- 0000 0000
| Step | Description | Result |
|---|---|---|
| Align bits | F0 = 11110000, 0F = 00001111 | 8 bits each |
| AND each bit pair | a result bit is 1 only where both inputs are 1 | no overlapping 1 bits |
| Result | no bit position has 1 in both operands | 0x00 |
F0 and 0F don't share any 1 bits, so ANDing them clears everything — this is exactly why AND is used to mask out (clear) bits you don't want.
Bitwise Operation Reference
| Operation | F0 . 0F | Result rule |
|---|---|---|
| AND (&) | 0x00 | 1 only where both bits are 1 |
| OR (|) | 0xFF | 1 where either bit is 1 |
| XOR (^) | 0xFF | 1 where the bits differ |
| NOT (~F0) | 0x0F | every bit flipped (8-bit width) |
Where Bitwise Operations Actually Come Up
Masking Out Unwanted Bits
ANDing a value with a mask clears every bit outside the mask, which is how low-level code isolates a specific field — like the low byte — out of a larger register.
value & 0xFF isolates the low byte
Combining Flag Bits
ORing individual flag values together sets multiple option bits at once without disturbing bits already set — the standard way permission and configuration flags get combined.
READ | WRITE combines two flags
Toggling Specific Bits
XORing a value against a mask flips exactly the bits in that mask and leaves everything else untouched — useful for toggling a status bit without needing to know its current state.
state ^ 0x01 flips the low bit
Why Use This Calculator Instead of Doing It by Hand
- Shows aligned binary for both operands and the result, not just the final hex
- Supports 8/16/32/64-bit widths, since NOT and OR results depend on width
- Runs entirely in your browser — nothing you type gets sent anywhere
- Covers all four core operations in one calculator instead of four separate tools
Limitations
- Results are bit-width dependent — the same NOT of 0x0F is 0xF0 at 8-bit but 0xFFF0 at 16-bit, so make sure the selected width matches your actual data type.
- Combines two values at a time (or one for NOT) — chain results manually for three or more.
Frequently Asked Questions
What operations does this bitwise calculator support?
AND, OR, XOR, and NOT — the four bitwise operations that cover the vast majority of masking, flag, and toggle logic in real code.
Why does bit width matter for bitwise operations?
A bitwise NOT on 0x0F at 8-bit width gives 0xF0, but the same NOT at 16-bit width gives 0xFFF0 — the result depends entirely on how many bits are involved, so always match the width to your actual data type.
What's the practical difference between AND, OR, and XOR?
AND clears bits (use it to mask), OR sets bits (use it to combine flags), and XOR toggles bits (use it to flip specific bits or compute a simple difference) — the operation to reach for depends on whether you're clearing, setting, or flipping.
Can I chain more than two values together?
This calculator combines two values (or one, for NOT) at a time — for three or more, apply the operation to the first two, then combine that result with the next value.
Does this show the binary bit-by-bit, not just the final hex result?
Yes — both operands and the result are shown in aligned binary underneath the hex output, so you can see exactly which bits combined to produce each result bit.
What is bitwise NOT actually used for?
Inverting a mask — if 0x0F selects the low nibble, NOT 0x0F gives you a mask that selects everything except the low nibble, at whatever bit width you're working in.
